TB82PH-ATEX-EN-A 13
CONFIGURE MODE
Before the instrument can be put into a process measurement loop it must be configured. The TB82PH Transmitter
operation (non-fieldbus versions) can be set in either a BASIC or ADVANCED Mode. BASIC mode is sufficient for 95% of
all measurements. ADVANCED functions are described in Italic print in the ‘alternatives’ section of the default
configuration table and in the ‘Configure Mode - Flow Chart for ADVANCED Mode’ section. Figures 15 through 25 show
typical screen flows for a BASIC pH Configuration.
Default Configuration
Parameter Default Alternative
Mode BASIC ADVANCED
Analyzer pH ORP, pIon,
Ion Concentration
Analyzer input pH Glass Antimony,
Custom sensor
Reference Impedance
Temperature Sensor None 3K Balco
Pt100 RTD
Temperature
Compensation Type
Manual Auto,
Auto Solution
Output 4 mA = 0.00 pH
20 mA = 14.00 pH
Any 1 pH to 16 pH span,
any span above 100 mV from
–1999 mV to +1999 mV,
non-linear function generator,
Damping 00.5 seconds Adjustable to 99.9 seconds
Diagnostics Off On
Safe Mode* Fail low Fail high
Spike* 0% Spike Magnitude 0 to 100% magnitude
Note: Alternatives in Italics are available in ADVANCED mode only
* Safe Mode and Spike functions not available on fieldbus versions
7.00
CONFIG
exit to
MEASURE SELECT
MENU
pH
MEASURE
CALIBRATE
OUT/HOLD
CONFIGURE
SECURITY
DISPLAY
MEASURE
CALIBRATE
OUT/HOLD
CONFIGURE
SECURITY
DISPLAY
7.00
MODIF
Y
exit to
MEASURE SELECT
NEXT
pH
MEASURE
CALIBRATE
OUT/HOLD
CONFIGURE
SECURITY
DISPLAY
7.00
Basi
c
exit to
MEASURE SELECT
NEXT
pH
MEASURE
CALIBRATE
OUT/HOLD
CONFIGURE
SECURITY
DISPLAY
7.00
ANALZR
exit to
MEASURE SELECT
NEXT
pH
Figure 15 Figure 16
Figure 17 Figure 18
