ABB TB82 Advantage Series User Manual

ABB TB82PH ATEX Product Instruction Manual
TB82PH-ATEX-EN-A 9
SENSOR CONNECTIONS – Model TB5 & TBX5 Sensor Connections
Figure 10 – TB5 cable with pin leads
RED
WHITE
BLACK
BLUE
To Sensor
Figure 9 - TB5 BNC cable & BNC adapter
To Sensor
RED
WHITE
4TB9515-0164 BNC Adapter
BLUE
BLACK
Figure 11 - TBX5 Advantage Sensor Cable
HEAVY
GREEN
YELLOW
RED
WHITE
BLACK
BLUE
GREEN
To Sensor
BLACK COAX with BNC
SENSOR CONNECTIONS
TB2
BLUE
YELLOW
BLACK
GREEN
RED
WHITE
HVY GRN
SENSE
GUARD
REF
SOL GND
RTD
RTD
SHIELD
1
2
3
4
5
6
7
8
Figure 8 – Sensor Connections
