ABB TB82PH ATEX Product Instruction Manual
TB82PH-ATEX-DE-A 49
ELEKTRISCHE ANSCHLÜSSE – Sensoranschluss bei den Modellen TB5 und
TBX5
Abb. 10 - TB5-Kabel mit Aderendhülsen
ROT
WEISS
SCHWARZ
BLAU
Zum Sensor
Abb. 9 - TB5 BNC-Kabel und BNC-Adapter
Zum Sensor
ROT
WEISS
4TB9515-0164 BNC-Adapter
BLAU
SCHWARZ
Abb. 10: TB5-Kabel mit Aderendhülsen
DUNKEL
GRUN
GELB
ROT
WEISS
SCHWARZ
BLAU
GRUN
To Sensor
COAX, SCHWARZ mit BNC
SENSOR CONNECTIONS
TB2
BLUE
YELLOW
BLACK
GREEN
RED
WHITE
HVY GRN
SENSE
GUARD
REF
SOL GND
RTD
RTD
SHIELD
1
2
3
4
5
6
7
8
Abb. 8: Sensoranschlüsse
