ABB Terra AC - Product Label (UL Portfolio)

A Brand
B Barcode with the serial number
C Barcode with the part number of
the EVSE
D Product model number
E MID accuracy class
F EVSE rating
G Mass of the EVSE
H Address of the manufacturer
I CE mark
J MID mark and notified body
number
K MID certificate number
L MID software checksum
M MID FW version
N Ingress protection rating
O Reference to the manual
Note: The data in the illustration is only an example. Find the product
label on your EVSE to see the applicable data. Refer to section 2.5.2.
2.4 Product label (UL portfolio)
SN: TACW7-[L]-WWYY-zxxxx
PN: XXXXXXXXXX
MODEL: Terra AC WX-P8-XX-XXX-X
TAC Wx-[L]-WWYY-zxxxx
XXXX XXXXXX
For use with electric vehicles
Pour utilisation avec des véhicules électriques
240V ~ / 60Hz 32A TYPE 3 -30ºC~50ºC
Ventilation Not Required Aucune ventilation requise
Raintight Étanche à la pluie Weight: 7.0kg
Dusttight Étanche à la poussière Poids: 7.0kg
A
B
C
D
E
F
G
H
A Serial number
B Part number of the EVSE
C Product model number
D Barcode with the serial number of
the EVSE
E Barcode with the part number of
the EVSE
F Power rating of the EVSE
G Ambient temperature
H Mass of the EVSE
Note: The data in the illustration is only an example. Find the product
label on your EVSE to see the applicable data. Refer to section 2.5.2.
Description
12 BCM.V3Y00.0-EN | 002
