ABB Terra AC - Technical data; EVSE Type

7 Technical data
7.1 EVSE Type
The EVSE type is a code.
The code has 10 parts: A1 - A10.
Code part Description Value Meaning of the val-
ue
A1 Brand name Terra AC -
A2 Type W Wallbox
C Column
A3 Power output 4 3.7 kW
7 7.4 kW
9 9 kW
11 11 kW
19 19 kW
22 22 kW
A4 Cable type or sock-
et
P Type 1 cable
G Type 2 cable
T Type 2 socket
S Type 2 socket with
shutter
A5 Cable length - No cable
5 5 m
8 8 m
A6 Authorization R RFID enabled
- No RFID
A7 Display D Yes
- No
A8 Metering M Certified for MID
(only with display)
- Not certified for
MID
A9 SIM slot C Yes
- No
A10 Ethernet - Single
D Daisy-chain
Example
Terra AC W7-P8-RD-MCD-0
• A1 = Brand name = Terra AC
• A2 = Type = wallbox
• A3 = 7, Power output = 7.4 kW
Technical data
BCM.V3Y00.0-EN | 002 47
