Operation Manual / 4 Product description / A100-L

Spare p

arts Page 107 /

113

HZTL4034_EN

Revision H

November 2016

Turbocharger

Part number

Designation

- - Cartridge group

51001 Gas inlet casing

56001 Nozzle ring

56011 (in the customer spare part set) Washer

56014 (in the customer spare part set) Hexagon-head screw

57001 Cover ring

57005 Hexagon-head screw

61001 Gas outlet casing

61009 Hexagon-head screw

68002 Foot, turbine end

72000 Compressor casing

72002 Threaded stud

72003 (in the customer spare part set) Washer

72004 (in the customer spare part set) Hexagon nut

72011 Hexagon-head screw

74040* Air-outlet silencer (option)

74042* Gasket (option)

77000 Wall insert

77015 (in the customer spare part set) Hexagon-head screw

77040 (in the customer spare part set) O-ring

79000 Diffuser

79020 (in the customer spare part set) O-ring

79021 (in the customer spare part set) O-ring

81000 Filter silencer

81300* Insulation ring (option)

81301* Gasket (option)

81302* Insulating disc (option)

Table 47: Turbocharger with part numbers

* Depending on the specification of the turbocharger
