Operation Manual / 4 Product description / A100-L
Page 60 /
© Copyright 2016 ABB. All rights reserved.
8.3 Disassembly and assembly of the filter silencer casing
Disassembly / Assembly of the filter silencer casing
This chapter applies only to turbochargers with filter silencer casing.
the assembly of the filter silencer casing is described in detail.
The disassembly must be carried out in
of the assembly.
Figure 22: Overview of filter silencer casing disassembly and assembly
01, 02 Bottom part
03, 04, 07, 08 Side part
05, 06, 09 Circumferential part
10, 11 Flange
The complete filter silencer casing has the part number 81500.
