Operation Manual / 4 Product description / A100-L
Page 11 /
© Copyright 2016 ABB. All rights reserved.
2 Removal and installation
2.1 Turbocharger weight
Lifting gear with a sufficient load limit must be used for removing and installing the turbo-
charger. The following weight specification applies to the heaviest variant possible. Depending
on the specification, the weight specified on the rating plate may be lower than the standard
value specified here.
A165-L 2300
A170-L 3300
A175-L 5600
A180-L 7500
A185-L 10500
A190-L 13500
Table 2: A100-L Weights
2.2 Removing the turbocharger
If the turbocharger is not sufficiently supported or not supported at all during
removal and installation, it may tip over and cause severe injury to personnel
or accidents resulting in fatalities.
Support the turbocharger at a suitable location.
Secure with lifting gear wherever possible.
Wear safety helmet.
Loosen cable to speed sensor.
Disconnect all pipes according to the instructions of the enginebuilder.
Check lifting gear.
Fasten lifting gear on suspension eyes of the bearing casing and tauten.
