ABB XAC18513 - Table 49: Cartridge Group with Part Numbers

Operation Manual / 4 Product description / A100-L
12 Spare parts / 12.3 View of cartridge group with part numbers
© Copyright 2017 ABB. All rights reserved. HZTL4034_EN Revision K June 2017
Cartridge group
Part number Designation
21000 Turbine
25000 Compressor wheel
25008 Threaded stud
25009 Ring nut
25011* O-ring
25012* Spinner nose cone
25013* Screw
25014* Washer
32001 Thrust bearing
32101 Radial bearing, compressor end
32102 Radial bearing, turbine end
32105 Floating disc
32106 Axial bearing
32109 Sealing disc
32159 Locking screw
32174 O-ring
42001 Bearing casing
42008 Socket screw
42011 O-ring
42015 Sealing cover
42039 Hexagon-head screw
42041 Gasket
42059 Hexagon-head screw
42064 Hexagon-head screw
42185 Socket screw
42186 O-ring
42295 Pressure adjusting unit
42300 Partition wall
42305 O-ring
42306 O-ring
42307 O-ring
42320 Socket screw
42458 Blind flange
86505 Speed sensor
86506 (in the customer spare part set) O-ring
Table49: Cartridge group with part numbers
* Depending on the specification of the turbocharger
Page 103 / 106
