ABB XAC18513 User Manual

Operation Manual / 4 Product description / A100-L
8
Disassembly and assembly
Page 88 /
113
© Copyright 2016 ABB. All rights reserved.
HZTL4034_EN
Revision H
November 2016
8.15 Fitting the filter silencer with noise package
Before fitting ensure that the individual sealing segments of the gasket (81301) and the gas-
ket (74042) are not damaged and that the contact surfaces are clean.
Figure 55: Fitting the filter silencer with noise package
Part number
A165-L
A170-L
A175-L
A180-L
A185-L
A190-L
72004 M14
130 Nm
M16
200 Nm
M18
300 Nm
M20
420 Nm
M22
570 Nm
M24
710 Nm
74043 M10
45 Nm
M10
45Nm
M10
45Nm
M10
45Nm
M10
45Nm
M10
45 Nm
Table 39: Tightening torques (72004, 74043)
