Operation Manual / 4 Product description / A100-L
Page 78 /
© Copyright 2016 ABB. All rights reserved.
Fitting the gas inlet casing
Figure 45: Fitting the gas outlet casing (A175-L and smaller)
61009 M16
30
1)
Nm
140 Nm
M18
40
1)
Nm
200 Nm
M22
50
1)
Nm
380 Nm
Table 32: Tightening torque (61009)
1) Pre-tightening torque of the screws
1. Fit two guide studs (90317) in the upper area on the gas outlet casing (61001).
2. Loop around the gas inlet casing (51001) with the lifting gear and secure it to the crane.
3. Push gas inlet casing over the guide studs up to the gas outlet casing.
4. Screw in two opposite screws (61009) with high-temperature grease.
5. Remove the guide studs (90317) and fit the remaining screws (61009) with high-
temperature grease.
6. Fit the screws (61009) by tightening them crosswise, first to the pre-tightening torque, then
to the tightening torque.
7. Remove the lifting gear.
8. Connect the flange of the gas inlet casing and the bellows.
