E-OCD II Debugger User’s Manual Debugger Software (for Microsoft Windows)
41
Figure 3-31 Dialog for E-OCD II Interface
Note : No device series will be selected by default. You must select one of the listed series;
else, this dialog box will not close
2) Turn off the target system and click Yes.
Figure 3-32 Message Box
3) Wait for a few seconds until the OCD interface re-configuration is completed.
4) Turn on the target system once the following message pops up.
Figure 3-33 Message Box
