Abus TVVR45021 - Substream Tab; Capture Tab; Advanced Settings; Holiday

Recording
45
Substream tab
The following parameters can be set:
Parameter
Setting
Camera
Camera to be set
Stream Type
Predefined video stream
Resolution
Auto, 4CIF(704x576),
CIF(352x288), QCIF(176x144)
Bitrate Type
Select a variable or constant bi-
trate
Video Quality
There are various quality levels:
+++: medium quality
++++++: high quality
Frame rate
Settings for the stream frame
rate
Max. Bitrate
Mode
General,
custom (32–3072)
Max. Bi-
trate(Kbps)
Display of the maximum bitrate
Max. Bitrate
Range Recom-
mended
192~320 (Kbps)
Confirm the settings by clicking on Apply and exit the
menu by clicking on Back.
Capture tab
The following parameters can be set:
Parameter
Setting
Camera
Camera to be set
Parameter type
Individual settings for continuous
and event recording.
Resolution
Auto, 4CIF(704x576),
CIF(352x288), QCIF(176x144)
Picture Quality
There are various quality levels:
+++: medium quality
++++++: high quality
Interval
Period after which single images
are saved (between 1 second
and
24 hours)
Confirm the settings by clicking on Apply and exit the
menu by clicking on Back.
Advanced settings
Overwrite
Specify whether older recordings
should be overwritten when the
hard disk drive is full.
Holiday
In this submenu, there are 32 different recording settings
for holidays or bank holidays.
Click on the "Edit" icon to apply these settings
