HDD
48
Click on Search to identify the network storage and then
click on OK to add the NetHDD.
The NetHDD must be initialised before use.
Advanced settings
Here you can define the settings for the storage mode.
Mode: Quota
In this mode, video data is divided between the total
number of data storage devices connected and written
onto them.
Selection of the camera channel
to be processed
Video storage space currently in
use on the linked data storage
devices.
Picture storage space currently
in use on the linked data storage
devices.
Total available hard disk drive
capacity (in GB).
Max. Record Ca-
pacity (GB)
Specify the maximum video re-
cording size on the linked data
storage devices for each camera.
Max. Picture Ca-
pacity (GB)
Specify the maximum picture re-
cording size on the linked data
storage devices for each camera.
When this function is activated,
idle hard disk drives go into
standby mode.
1. Use Copy to specify if the setting is to be applied to
all cameras.
2. Confirm the settings by clicking on Apply and exit the
menu by clicking on OK.
The group of hard disk drives will be saved.
3. Click on Apply and confirm the reboot in the next
window by clicking on OK.
Mode: Group
In this mode, video data can be specifically (and also re-
dundantly) stored on selected data storage devices.
Select which cameras should be
stored in the group currently se-
lected.
When this function is activated,
idle hard disk drives go into
standby mode.
The HDD groups are configured in the General menu. To
do this, click on to open the HDD group settings.
Choose from eight NetHDDs.
NAS: For this setting, your net-
work storage must support the
NFS file system.
IP SAN: For this setting, your net-
work storage must support the
iSCSI protocol.
Enter the network storage IP ad-
dress.
Enter the storage path or iSCSI
target.
