AC Tech MC1000 series User Manual

DIAGRAM A - EXPLODED VIEW
0.5 - 5 HP, 240/200 Vac
1 - 7.5 HP, 480/400 Vac
1 - 7.5 HP, 590/480 Vac
SCREW (TYPICAL 4 PLCS.)
SHOULDER WASHER
(TYPICAL 4 PLCS.)
1 5/16" STANDOFF
(TYPICAL 3 PLCS.)
LOCATION OF P8 & P9 ON 7.5
HP DB BOARD (9956-XXX)
2 X 6 PIN CONNECTOR
3/4" STANDOFF
SHOULDER WASHER
STANDOFFS ONLY
PRESENT IN 7.5 HP KIT
(9956-XXX DB BOARD)
7/16" STANDOFF

AC Tech MC1000 series Specifications

General

Brand	AC Tech
Model	MC1000 series
Category	DC Drives
Language	English
