QUALITY CONTROLS - 5
VerifyNow System User Manual Page 35 14340.J
Figure 5-16 WQC Level 1 Result
19.
Open the cover. Remove the assay device and tube together in one piece by
grasping the assay device finger grip and pulling straight up (Figure 5-17). Never
separate the tube from the assay device. Close the cover. Discard the assay
device and tube in a biohazard waste in accordance with institutional guidelines.
Figure 5-17 Remove Device
20.
At the conclusion of the test, the resulting value will be displayed on the screen.
Look up the expected values printed on the assay device pouch for Control 1
(Figure 5-18).
Figure 5-18 Interpreting WQC Level 1 Results
21.
Compare the WQC result to the Control Level 1 range, and verify the result falls
within the expected range. If the result falls within the expected range, the
Control Level
1 Range
To Next Page
