Acer AOHAPPY2 - Upper Case Installation

3-20 Machine Maintenance Procedures
(Figure 3-16).
Figure 3-16. Touchpad FPC Removal
Upper Case Installation 0
1. Connect the touchpad FPC (E) to the touchpad module (D) (Figure 3-16).
2. Install the upper case on the lower case.
3. Connect the touchpad FPC (A) to the mainboard connector (B) (Figure 3-15).
4. Install the base cover.
D
E
