Acer AOHAPPY2 - HDD (Hard Disk Drive) Removal

3-14 Machine Maintenance Procedures
HDD (Hard Disk Drive) Removal 0
Prerequisite:
Base Cover Removal
1. Find HDD (A) on the lower case (Figure 3-9).
Figure 3-9. Component Location
2. Disconnect the hard drive cable (A) from the mainboard connector (B) (Figure 3-10).
Figure 3-10. Hard Drive Cable Removal
A
C B
A
B
