System Utilities 2-25
Using the LAN MAC EEPROM Utility 0
Perform the following steps to write MAC (Media Access Control) information to
EEPROM:
Use the LAN.BAT utility to write the MAC.CFG file to the EEPROM under DOS mode.
1. Use a text editor (Ex: Notepad) to open the MAC.CFG file. See the MAC.CFG contents
in Figure 2-30
Figure 2-30. LAN MAC EEPROM
2. Enter into DOS.
3.
Run the LAN.BAT file to write MAC values to EEPROM.
4. Reboot the system when the process has completed.
Table 2-6. LAM MAC EEPROM
Parameter Description
WriteData = ‘001122334455' MAC value
StartAddr=7A MAC address
WriteLeng=6 MAC value length
KeepByte=0 Value not important
