3-12 Machine Maintenance Procedures
Keyboard FPC (Flexible Printed Circuit) can be damaged if removed while the
mainboard connector is locked.
Keyboard Installation 0
1. Put the keyboard face down on the upper case (C). Refer to Figure 3-7.
2. Connect the keyboard FPC (A) to the mainboard connector (B). Refer to Figure 3-7.
3. Turn the keyboard over and align the keyboard with the indentation in the upper
cover.
4. Press down to secure the latches on the upper cover. Refer to Figure 3-6.
5. Install the battery.
