Acer AOHAPPY2 - Microphone Removal

3-32 Machine Maintenance Procedures
Microphone Removal 0
Prerequisite:
LCD Bezel Removal
1. Find the microphone (A) on the LCD module (Figure 3-28).
Figure 3-28. Microphone and Camera Module Locations
2. Remove the microphone from the LCD module as shown in Figure 3-29.
NOTE:
NOTE:
Use care not to damage the microphone.
C
A
B
B
