Machine Maintenance Procedures 3-37
LCD Panel Installation 0
1. Place the LCD panel on the LCD cover. Refer to Figure 3-33.
2. Install and secure four (4) screws (C) to the LCD panel. Refer to Figure 3-32.
3. Connect the camera cable (A) to the camera connector (B). Refer to Figure 3-31.
4. Install the LCD hinge.
ID Size Quantity Screw Type
C M2.0*3.0 NI 4
To Next Page
