Acer AOHAPPY2 - LCD Module Removal

3-28 Machine Maintenance Procedures
LCD (Liquid Crystal Display) Module Removal 0
Prerequisite:
Mainboard Removal
1. Remove the two (2) screws (A) from the LCD hinges (Figure 3-23).
Figure 3-23. LCD Hinge Screws
2. Lift the LCD module upward from the lower base (Figure 3-24).
A
