Hardware Specifications and Configurations 1-13
Figure 1-2. Closed Front View
Table 1-2. Closed Front View
# Icon Item Description
1 Power indicator Indicates the computer's power status.
Battery indicator Indicates the computer's battery status.
1. Charging: The light shows amber when
the battery is charging.
2. Fully charged: The light shows blue
when in AC mode.
Communication
indicator
Indicates the status of 3G / Wi-Fi
communication
Blue light on Orange light
on
Not lit
3G on / Wi-Fi on
3G on / Wi-Fi off
3G off / Wi-Fi
on
3G off /
Wi-Fi off
