X1161/X1261/X1161A/X1161N/X110/H5360
Condential
iv
Assemble Bottom Shielding 2-17
Assemble Interrupt Switch 2-17
Assemble Lamp Driver Module 2-18
Assemble LVPS Module 2-19
Assemble Blower 2-19
Assemble System Fan Module 2-20
Assemble Focus Ring 2-21
Assemble Zoom Ring 2-21
Assemble DMD Chip and DMD Board 2-22
Assemble Color Wheel Module 2-22
Assemble Engine Module 2-23
Assemble IO Cover and Main Board Module 2-23
Assemble IR Sensor Board and Front Cover 2-25
Assemble Top Shielding 2-26
Assemble Top Cover Module 2-26
Assemble Lamp Module 2-27
Assemble Lamp Cover Module 2-27
Chapter 3 Troubleshooting
LED Lighting Message 3-1
Main Procedure 3-2
Chapter 4 Function Test & Alignment Procedure
Test Equipment Needed 4-1
Service Mode 4-1
OSD Reset 4-1
Test Condition 4-2
Test Inspection Procedure 4-3
PC Mode 4-4
