Acer X110 - Chapter 3 Troubleshooting; 3-1 LED Lighting Message

X1161/X1261/X1161A/X1161N/X110/H5360
Condential
3-1
Chapter 3
Troubleshooting
3-1 LED Lighting Message
Message
Power LED
Red Blue
Input Power Plug Flash ON to OFF 100ms --
Standby V --
Power button ON -- V
Lamp retry --
0.5 second H(On),
0.5 second L(Off) ashing
Power off
(Cooling state)
0.5 second H(ON),
0.5 second L(OFF) ashing
--
Power button OFF:
Cooling completed;
Standby Mode
V --
Error (Thermal
Failure)
0.5 second H(On), 0.5 second L(Off) ashing red twice, and blue
LED ON 2 second, and by returns
Error (Fan lock)
0.5 second H(On), 0.5 second L(Off) ashing red twice, and blue
LED ON 2 second, and by returns
Error (Lamp break-
down)
0.5 second H(On), 0.5 second L(Off) ashing blue twice, and red
LED ON 2 second, and by returns
Error (Color Wheel
Failure )
0.5 second H(On), 0.5 second L(Off) ashing blue twice, and red
LED ON 2 second, and by returns
Note: Steady Light: "V"
No Light: "--"
