Acer X110 - 4-5 Test Inspection Procedure

Condential
4-3
X1161/X1261/X1161A/X1161N/X110/H5360
4-5 Test Inspection Procedure
Update
Change parts
Main
Board
Firmware
Color
Wheel
Lamp
Module
Engine
Module
EDID
Lamp
Driver
Version Update v v
Color Wheel Index v v
PC Calibration v v
Video Calibration v v
G Sensor Calibration v v
Reset Lamp Hour v v
OSD Reset v v
EDID v
Re-write Lamp
Hour Usage
v
Reset Default
Language
v v v v
Rod adjustment v
Waveform Download v
Note: - If Color appears abnormal after changing Main Board Module, please do Color Wheel index
adjustment.
- After changing parts, check the information above table.
Defect specication table
Order Symptom Pattern Criteria
1 Bright pixel (dots) Gray 10 pattern A+B≤ 1
2 Dark pixel (dots) White pattern A+B ≤ 6
3 Bright blemish Gray 15 pattern A+B ≤ 10
4 Dark blemish Blue 60 pattern A+B ≤ 10
5 Bright dot on frame Gray 10 pattern ≤ 1
6 Unstable pixel White & Black pattern A+B ≤ 1
7 Adjacent dark pixel White & Black pattern A+B = 0
