8. SPECIFICATIONS
8.1. Parameters
a) Frequency Coverage*
1.800 - 2.000 MHz (160 m band)
3.500 - 4.000 MHz (80 m band)
5.020 - 5.455 MHz (60 m band)**
7.000 - 7.300 MHz (40 m band)
10.100 - 10.150 MHz (30 m band)
14.000 - 14.350 MHz (20 m band)
18.068 - 18.168 MHz (17 m band)
21.000 - 21.450 MHz (15 m band)
24.890 - 24.990 MHz (12 m band)
28.000 - 29.700 MHz (10 m band)
50.000 - 54.000 MHz (6 m band)**
* Extensions or changes of the frequency coverage are possible on request.
** Please, refer the applicable regional band plans and laws for specific allocations
and limitations.
b) Rated Output Power
• 1500 W, PEP or continuous carrier, no mode limit;
c) Intermodulation Distortions (IM3)
• Better than 30 dB below rated PEP;
d) Harmonic and Parasitic Emissions Output Suppression
• 1.8-29.7 MHz - better than 60 dB below rated output;
• 50-54 MHz - better than 70 dB below rated output;
e) Input and Output Impedances
• Nominal value: 50 Ohm unbalanced, UHF (SO-239A) type connectors;
• Input: Broadband, SWR below 1.2 (1.1 typically), 1.8-54 MHz continuous range without
retuning or switching;
• RF bypass: SWR - below 1.1, 1.8-54 MHz;
• Output: Antenna SWR below 1.5 is recommended; up to SWR 3 is allowable with
proportional power reduction;
