necessary to apply to the cone a disposable protective cover designed to cover the end part of the X-ray generator.
Such protection has two functions: avoid cross-contamination (from patient to patient) and prevent the possibi-
lity of inammations or other types of reactions of the skin caused by contact with the material that constitutes
the cone.
OPTIONAL ACCESSORIES
}SECOND CONTROL BUTTON
}Xmind®dc LIGHT (Rx signalling lamp for external use)
}Xmind®dc ECB (remote control button)
PLEASE NOTE
For the installation of the optional accessories, refer to the specic installation manuals supplied.
2.3. OVERALL DIMENSIONS
Fig. 2A, 2B, 2C give the overall dimensions of the possible supply conditions:
BRACKET 400: L = 16” 9/64
BRACKET 800: L = 82,5cm – 32” 31/64
BRACKET 1100: L = 110cm – 43” 5/16
BRACKET 400
