ENGLISH
INSTALLATION & MAINTENANCE MANUAL • XMIND DC • W1100100 • V1 • (15) • 12/2015 • NXDCEN020B
CHAPTER 5
5.1. ELECTRIC CONNECTION
CAUTION
Before proceeding to connections, the power supply must be cut off.
CAUTION
For electric safety, it is essential that the ground conductors are correctly connected.
!
WARNING
While performing the connection, always respect the polarity PHASE/ NEUTRAL.
!
WARNING
While stripping the cables, pay attention to the small copper wires that may fall on the printed circuit and cause short circuits or malfunc-
tioning.
CONNECTION INSTRUCTION TO THE FEEDING TERMINAL BOARD
1. Remove the terminal board cover 1 by unscrewing the xing screw 2.
