INSTALLATION & MAINTENANCE MANUAL • XMIND DC • W1100100 • V1 • (15) • 12/2015 • NXDCEN020B
4.6. ASSEMBLING THE TIMER
CAUTION
Check that the cable runs are arranged in the timer installation wall; check the compliance of the power supply with the installation specica-
tions (refer to Chapter 3).
!
WARNING
Check that the rating data match the power supply voltage.
!
WARNING
When the timer is installed aside the wall plate, please do as follows:
} the timer must be mounted on the left side of the wall plate;
} the distance between timer and wall plate must be 2,5mm;;
