CHAPTER 13
13.1. REPLACEMENT OF FUSES
The timer electronic equipment is protected by n° 4 fuses located on the electronic board.
To replace them proceed as follows:
INSTRUCTION
1. Out off the power supply.
2. Temporarily remove the guard of the timer 1 by unscrewing the xing screws 2.
3. Spot the fuse to be replaced.
4. Remove the plastic protection.
