INSTALLATION & MAINTENANCE MANUAL • XMIND DC • W1100100 • V1 • (15) • 12/2015 • NXDCEN020B
ENGLISH
5. Withdraw the fuse.
6. Replace it with one of the same type.
NOMINAL VOLTAGE 230 V ± 10% 115 V ± 10%
PROTECTION FUSES 8 AF – 250 V 12 AF – 250 V
7. Put in place the protection.
8. Close the timer guard.
9. Turn on the power supply.
