ENGLISH
INSTALLATION & MAINTENANCE MANUAL • XMIND DC • W1100100 • V1 • (15) • 12/2015 • NXDCEN020B
ANNEX 6
A6. DRAWINGS AND DIMENSIONS
WALL INSTALLATION
Lateral view (rest position)
Bottom mount
A
40 cm (16’’) bracket 63 cm
80 cm (31’’) bracket 104 cm
110 cm (43’’) bracket 132 cm
A6A6
