CHAPTER 3
3.1. INSTALLATION SPECIFICATIONS
!
WARNING
Prior to installing the radiographic system the Ofce Owner must ascertain that:
the environment, the electric system and the power supply comply with the requirements needed, otherwise he must provide the required
adjustment.
ENVIRONMENT REQUIREMENTS
- The installation environment must be wide enough: check that the size and overall dimension of the environment
don’t present any obstacle while positioning the radiographic system.
- The environment must not be exposed to explosion hazards and must not be pressurized.
- While operating, the ambient temperature must range within +5°C and +40°C.
- The storage temperature must range within -15°C and +50°C.
- The relative humidity must range within 25% and 75%.
REQUIREMENTS OF THE SUPPORTING WALL
- The radiographic system supporting wall must be able to stand 200 Kg tear at every xing point.
PLEASE NOTE
It is mandatory to check the nature and consistency of the wall; if required, ask the support of a brickwork expert.
The walls of uncertain consistency must be provided with a buried counter plate or with a sandwich type system.
REQUIREMENTS OF THE ELECTRIC SYSTEM
- The electric system must comply with the regulations in force.
- The electric system must be able to supply the power and voltage required in the manufacturer’s rating plate of
the radiographic system (Chart A).
Chart A
MANUFACTURER’S RATING PLATE
ELECTRIC SYSTEM
230 V ± 10% 115 V ± 10%
NOMINAL VOLTAGE 230 V 115 V
MINIMUM LINE VOLTAGE 207 V 103,5 V
MAXIMUM LINE VOLTAGE 253 V 126,5 V
FREQUENCY 50 / 60 Hz 50 / 60 Hz
ABSORBED POWER 1,2 kVA 1,1 kVA
REQUIREMENTS OF THE ELECTRIC LINE
- The electric line must be “single phase alternate” type.
- It is essential a 16A – 250V, magnetothermic differential switch be t upstream the radiographic system, with
differential protection In 30mA (refer to Chapter 15).
- The power conductors of the timer and the connection conductors with the tubehead must be two-pole +
ground, and must bear suitable section to the length of the power supply line (Chart B).
