CHAPTER 9
9.1. DIAGNOSTIC
With “Xmind®dc” radiographic system it is possible to set and visualise certain functional parameters.
To set the parameters, the installer must:
1. turn off the timer;
2. press simultaneously and keep pressed the keys:
(45) MANDIBULARY LOWER MOLAR
(43) MANDIBULARY LOWER CANINE
3. turn on the timer;
4. when the message INST is displayed, the installer can set the minimum exposure time in this way:
►select the tubehead;
►turn off the timer;
►turn on the timer, by keeping pressed the key;
►the message SEC is displayed for approximately 1s;
►the present value of the lower set limit is displayed;
►to change the value, press the keys ;
►to conrm press the key;
5. to exit this mode, turn the timer off and then on again.
!
WARNING
Both in digital and in conventional mode, the minimum exposure time must not be less than 0.02s.
To visualise the parameters proceed as follows:
1. press simultaneously and keep pressed the keys:
(17) MAXILLA MOLAR
(47) MANDIBULARY MOLAR
2. press the key associated to the parameter one wishes to visualise:
99
