INSTALLATION & MAINTENANCE MANUAL • XMIND DC • W1100100 • V1 • (15) • 12/2015 • NXDCEN020B
REF SPARE PARTS BRACKET
CODE
(RAL 9010 color)
OLD COLOR Q.TY PCS
BRACKET 400 29700380.C 29700380 COMPLETE
BRACKET 800 29700378.C 29700378 COMPLETE
BRACKET 1100 29700379.C 29700379 COMPLETE
1 BRACKET CAP COVER + SCREW RAL 9010 29701281.C 2
2
BRACKET SLIDE COVER AC/DC 14X1.4cm
RAL 9010
27502305 3
3 BRACKET ROTATION STOPPER 29701008 5
