Guidance and manufacturer’s declaration – electromagnetic immunity
“Xmind®dc” is intended to be used in the electromagnetic environment specied below. The customer or
“Xmind®dc” operator must ensure that the device is used in this type of environment.
Immunity test CEI EN 60601 test level Compliance level
Electromagnetic environment
guidance
Electrostatic
discharge (ESD)
CEI EN 61000-4-2
+/- 6 kV contact
+/- 8 kV air
CEI EN 60601-1-2
Test level
Floors should be wood, concrete or
ceramic tile. If oors are covered
with synthetic material, the relative
humidity must be at least 30%
Electrical fast
transient/burst
CEI EN 61000-4-4
+/- 2 kV for power supply lines
+/- 1 kV for input/output lines
CEI EN 60601-1-2
Test level
Mains power quality should conform
to that of typical commercial or
hospital applications.
Surge
CEI EN 61000-4-5
+/- 1 kV differential mode
+/- 2 kV common mode
CEI EN 60601-1-2
Test level
Mains power quality should conform
to that of typical commercial or
hospital applications.
Voltage dips, short
interruptions and
voltage variations
on power supply
input lines
CEI EN 61000-4-11
<5 % UT for 0.5 cycles
(>95 % dip in UT)
40 % UT for 5 cycles
(60 % dip in UT)
70 % UT for 25 cycles
(30 % dip in UT)
<5 % UT for 5 onds
(>95 % dip in UT)
CEI EN 60601-1-2
Test level
Mains power quality should
conform to that of typical
commercial or hospital applications.
If the “Xmind®dc” operator
requires continued operation even
during mains power outage, we
recommend powering the system
using a UPS.
Mains frequency
(50/60 Hz)
magnetic eld
CEI EN 61000-4-8
3 A/m
CEI EN 60601-1-2
Test level
Power frequency magnetic elds
must be at the typical level of
standard mains for commercial or
hospital use.
Note: Ut is the AC mains voltage prior to the application of the test level.
