Advanced Instruments OsmoPRO MAX User Manual

Chapter 2: Installation and Setup
OsmoPRO MAX Automated Osmometer User Guide
35
1. On the Home screen, make sure you have an active
LAN ( ) or LIS ( )connection. If you do not, refer
to Set Up Networking Communications.
2. Select > Settings > Networking and log in to the
Admin account (see Logging in to the Admin User
Account).
3. Press the Peer Group tab.
4. To enable QC records uploading, select a Monthly or
Daily automatic upload, or select to Manually upload.
5. Press Test to test the connection to the AdvancedQC
Peer Group Program.
If the Test Result shows FTP login test success, the
instrument connected to the site and can upload QC
tests using Protinol™ and Renol™.
If the Test Result shows FTP login test failed, the
instrument could not connect to the site.
a. If the LAN/LIS status still shows active, power o
the instrument and wait 15 seconds.
b. Power on the instrument.
c. If you still cannot connect to the AdvancedQC Peer
Group Program from the Peer Group tab, contact
AI Service (seeContacting Advanced Instruments).
Change Hardware Options
You can change the system audio, screen brightness, and
barcode scanner settings.
NOTE: Access to Settings> H/W Options depends on
the Change Hardware Options checkbox setting
on the Operator Permissions tab (see Configure
Operator Permissions).
Change the Audio Click Tone
You can change the click tone that sounds and its
volume when you press a button on the screen.
1. Press > Settings >H/W Options and login.
2. Select a click tone and then a volume to test the
tone/volume combination.
NOTE: Select O to disable click tones.
3. Press Save to save the selected tone and volume.
4. Press Exit to return to the Settings menu.
NOTE: To test/hear the tone that sounds when an error
occurs, press . The error tone/volume cannot
be changed.
