PPC-3150/3170 User Manual 2
1.1 Introduction
The PPC-3150&3170 with 15”&17” Fanless panel PC doesn’t only deliver high per-
formance by Intel Atom processor but also supports a wide operating temp. (-20 ~
60
° C) and wide range of power input (9 ~ 32 Vdc). It consolidates performance and
reliability in one system. With rich I/Os as four COM (two internal ports optional for
COM module), one USB 3.0, one isolated RS-422/485 and dual Intel Gigabit Ether-
net make it easier to connect to devices and be integrated into machine building
industry. The PCI/PCIe expansion is allowed to add on field bus or proprietary card
makes more application possibility.
1.2 Specifications
1.2.1 Specification Comparison
Product PPC-3150 PPC-3170
LCD Specification 15’’ LCD 17’’ LCD
Display Type 15" TFT LCD (LED backlight) 17" TFT LCD (LED backlight)
Max. Resolution 1024 x 768 1280 x 1024
Color 16.7M 16.7M
Dot matrix 0.297 x 0.297mm 0.264 x 0.264mm
Viewing Angle
80 (left), 80 (right),
70 (top), 70 (bottom)
80 (left), 80 (right)
60 (top), 80 (bottom)
Brightness 400 cd/m2 350 cd/m2
Contrast 700 800
Backlight Lifecycle 50, 000 hours 50, 000 hours
Weight 5.3 kg (11.6 Ib) 6.27 kg (13.9 Ib)
Dimensions
396.5 x 317.6 x 65.3 (mm)
(15.6" x 12.5" x 2.57")
442.0 x 362.0 x 69.5 (mm)
(17.4" x 14.25" x 2.73")
