PPC-3150/3170 User M
anual
36
3.
Follow S
tep 5 in Section A to fix MiniSA
T
A to SA
T
A board.
4.
Connect the other end of SA
T
A+SA
T
A Power line, then bind the cables with
cable tie. (See Figure 2.46)
Figure 2.46
5.
Follow S
tep 7 in Section A to fix VESA ir
onware.(See Figure
2.47) Then replace
the rear cover and fix it to finish the inst
allation.
Figure 2.47
Note!
The module does no
t support AHCI mode, which should be configured
in BIOS. Please refer to Section 4.2.8 for deta
ils.
