PPC-3150/3170 User M
anual
44
3.1
Jumpers and Connectors
Figure 3.1
Connector
Funct
ion
CN5
SA
T
A1 power
CN12
Internal USB
CN14
T
ouchscreen power
CN15
T
ouchscreen connec
tor
CN16
LCD selection
CN17
L
VD
S
CN21
S
peaker
CN26
Pin9 power selection (COM1 & CO
M2)
CN31
Isolated COM
CN32
Input power
CN33
Power button
CN34
GPIO
CN35
SMBUS
CN37
Driving board
CN38/39
COM4/COM5
CN40
USB HUB (Select by switch)
SW2
A
T
X/A
T switch
JP1
Clear CMOS
JP2/JP3
LCD power selection
SA
T
A1
SA
T
A1
JP2
CN17
CN16
CN37
JP3
CN14
CN15
S
ATA
1
CN34
CN40
CN38
CN39
CN35
CN21
CN12
CN5
JP1
CN26
SW2
CN32
CN31
51
53
