Advantech PPC-3150 User Manual

3 PPC-3150/3170 User Manual
Chapter 1 General Information
1.2.2 General Specifications

1.2.3 PowerSpecifications
Model No. Frequency Cache
CPU Atom E3845 1.91 GHz 2 M
Chipset Intel Atom Processor E3800 Series
Memory 1 x 204-pin slot support up to 4 GB DDR3L
Storage 1 1 x 2.5” SATA bay
Optional Storage & I/O
Either one
 1 x Full size mSATA
 CFast card (optional module)
 CF card (optional module)
 Internal USB connector for USB dongle (optional module)
 2 x DB9 for two RS-232 or one RS-232 and one GPIO
(optional module)
Network (LAN) 2 x Gigabit Ethernet (Intel I210)
I/O Ports
 1 x isolated RS-422/485
 4 x RS-232 (2 internal for optional COM module)
 1 x GPIO (8 channels, TTL level) (Reserved)
 1 x USB 3.0 + 3 x USB 2.0
 2 x Gigabit Ethernet
 1 x D-SUB VGA port
 1 x DP1.1a port
 1 x Line-out, 1 x Mic-in, 2 x 1 W speaker (internal)
Expansion Slots
Either one:
 1 x PCI (standard)
 1 x PCIe x 1 (in the accessory box)
Other Expansions 1 x Full-size Mini PCIe slot
OS Support WES7 / Windows 7 / Windows 8
Model Name PPC-3170 PPC-3150
Power Con-
sumption
34 W (Test system: Win7 32 bit) 30 W (Test system: Win7 32 bit)
Output Power 50 W
Input Voltage
9 ~ 32 V
DC
, 6 A ~ 2 A
Note! For test conditions for above power consumption, please refer to Note 1
and Note 2.

Advantech PPC-3150 Specifications

General

Brand	Advantech
Model	PPC-3150
Category	Touch Panel
Language	English
