IST Series UPS (10kVA-200kVA)
User Manual 2 Overview
13
Operation panel
IST7 series UPS (10kVA-140kVA)
Figure2-5 Operation panel
IST7 series UPS (160kVA-200kVA)
Figure2-6 Operation panel
Table2-1 Illustration for the operation panel
NO. Name Illustration
○
,1
Touch screen
Shows the running parameters (such as voltage,
current, load, etc.) and status
