4 Touch Screen
IST Series UPS (10kVA-200kVA)
User Manual
50
: Warning.
: ON/OFF.
The work status and energy flow on main page shows the system running status and unit
running condition directly.
4.3 System Work Status Display
The system work status includes: initializing, shutdown, exit parallel system, maintenance
bypass output, bypass output, battery inverter output, mains inverter output, grid-connected
aging, ECO bypass output, frequency conversion INV. output, aging bypass output, fault
protection. Each page is as shown fromFigure4-3 to Figure4-14.
Figure4-3 Initializing
Figure4-4 Shutdown
