A Technical Specifications
IST Series UPS (10kVA-200kVA)
User Manual
88
A Technical Specifications
Model
Index
10kVA
20kVA
30kVA
40kVA
50kVA
60kVA
80kVA
100kVA
140kVA
160kVA 200kVA
Input
Input mode 3φ4W+PE
Rated input voltage
(VAC)
220/230/240 (phase voltage)
Input voltage range
Vin=176Vac~280Vac, Do not decrease rated power to use.
Vin=80Vac~175Vac, Linear decrease rated power to use.
Input frequency range
(Hz)
40~70
Bypass synchronization
tracking range (Hz)
50/60±6
Bypass input voltage 220/230/240 (phase voltage)
Input power factor ≥0.99
Input THDI Resistive full load:≤3%; non-linear full load:≤5%
Battery (VDC)
+180~+240 (can be selected from +15cells~+20cells, default is +16
cells)
Charge current (A) 10 20 20 30 40 50
Output
Output mode 3φ4W+PE
Output wave Sine-wave
