 Avoid any object block the ventilation hole on the front panel and rear panel, which is to
keep good ventilation for the UPS, or, it may rise the inner temperature, even influence
the UPS service time.
3.2.4 Selection for Input and Output Wires
For the wire sectional area selection of AC input and output wires, please refer to Table3-1
and Table3-2 for corresponding recommended values, and choose upwards.
Table3-1 Recommended wire and terminal specification 1
Model
Item
10kVA 20kVA 30kVA 40kVA 50kVA 60kVA
Mains input
Mains input current (A) 25 40 55 71 95 111
Recommend
ed wire
sectional area
(mm
2
)
U/V/W/N 4×4 4×10 4×16 4×16 4×25 4×35
Wire terminal model DT4 DT10 DT16 DT16 DT25 DT35
Bypass input
Bypass input current (A) 15 30 45 61 76 91
Recommend
ed wire
sectional area
(mm
2
)
U/V/W/N 4×2.5 4×6 4×10 4×16 4×16 4×25
Wire terminal model DT2.5 DT6 DT10 DT16 DT16 DT25
Output
Output current(A) 15 30 45 61 76 91
Recommen
ded wire
sectional
area (mm
2
)
U/V/W/N (when
the load is non-
linear load, the
N wire should
increase the
wire sectional
area)
4×2.5 4×6 4×10 4×16 4×16 4×25
