AEG IST7 - Setting Management

IST Series UPS (10kVA-200kVA)
User Manual 3 Installation
27
Model
Item
10kVA 20kVA 30kVA 40kVA 50kVA 60kVA
Wire terminal model DT2.5 DT6 DT10 DT16 DT16 DT25
Battery input
Battery nominal discharge
current (the current value of
384V voltage when standard
equipped with 32 pieces 12V
storage battery) (A)
28 55 82 110 137 164
Battery max. discharge current
(the current value when
standard equipped with 32
pieces 12V storage battery
stop discharge <each piece
voltage is 10.5V>) (A)
35 63 94 125 157 188
Recommended wire
sectional area
(mm
2
)
+/N/- 3×6 3×10 3×16 3×35 3×50 3×70
Wire terminal model DT6 DT10 DT16 DT35 DT50 DT70
Grounding wire
Recommended wire
sectional area
(mm
2
)
PE 4 10 16 16 16 25
Wire terminal model
DT4
DT10 DT16 DT16 DT16 DT25
Table3-2 Recommended wire and terminal specification 2
Model
Item
80kVA 100kVA 140kVA 160kVA 200kVA
Main
Mains input current (A) 138 190 207 276 380
