IST Series UPS (10kVA-200kVA)
User Manual 4 Touch Screen
57
4.4.4 System Output Information Page
In main page, click icon, it will enter system output information page, as shown in
Figure4-21. In the page, it shows the current three-phase output voltage, current, active power,
apparent power, load percentage and frequency.
Figure4-21 System output information
4.5 Information Query
In main page, click icon, it will enter information query page, as shown in Figure4-22.
Figure4-22 Information query
It can record 9000 pieces information at most. When the record exceeds 9000 piece, the
earliest information will be covered by new one. All records is ranked in inverted order of time.
