AEG IST7 - System Management

3 Installation
IST Series UPS (10kVA-200kVA)
User Manual
28
Model
Item
80kVA 100kVA 140kVA 160kVA 200kVA
Recommend
ed wire
sectional area
(mm
2
)
U/V/W/N 4×50 4×70 4×95 4×120
(4×95)
×2
Wire terminal model DT-50 DT-70 DT-95 DT-120 DT-95
Bypass input
Bypass input current (A) 122 152 182 244 304
Recommended wire
sectional area
(mm
2
)
U/V/W/N 4×35 4×50 4×70 4×95
(4×70)
×2
Wire terminal model DT-35 DT-50 DT-70 DT-95 DT-70
Output
Output current(A) 122 152 182 244 304
Recomme
nded wire
sectional
area
(mm
2
)
U/V/W/N(when the
load is non-linear
load, the N wire
should increase
the wire sectional
area)
4×35 4×50 4×70 4×95
(4×70)
×2
Wire terminal model DT-35 DT-50 DT-70 DT-95 DT-70
Battery input
Battery nominal discharge
current (the current value of
384V voltage when standard
equipped with 32 pieces 12V
storage battery) (A)
219 274 329 438 548
